PARAGON EM

The Metrol PARAGON EM System records and wirelessly transmits pressure and temperature measurements from multiple discrete locations in the well.

Specifications

0 - 25,000 psi (30,000 psi available on request)

PRESSURE RANGE

+/-1°C

TEMPERATURE ACCURACY

Up to 10 years

GAUGE BATTERY LIFE

No depth limit

TRANSMISSION RANGE

Up to 7 years

TRANSMISSION LIFE

128 points per second to multiple long term options

ADJUSTABLE SAMPLE RATE



FEATURES

  • High accuracy, high resolution data collected from OCULUS gauges
  • Engineered to fit with standard industry completion and abandonment equipment
  • Multiple surface sonar options including autonomous vehicles
  • Long term observation and well test gauges built using the same transducer specification, providing directly comparable data sets
  • Modular equipment and simple interfacing, gained through years of industry deployment experience
  • Can be integrated with other Metrol telemetry, sensor and actuation systems


BENEFITS

  • Safer well abandonment; the barrier envelope can be monitored for several years
  • Cost effective:
    • No requirement to bring a rig back to location while maintaining surface read out
    • Low volume of equipment required in hole
  • Advanced reservoir understanding - continuous survey and no loss of data between drilling, well test and abandonment phases
  • Comprehensive barrier qualification and monitoring data
  • All data recorded to gauge memory and never lost

APPLICATIONS

  • Well testing
  • Extended well testing
  • Observation / appraisal wells (long term monitoring)
  • Permanent abandonment
  • Barrier monitoring
  • Barrier verification
  • Reservoir monitoring
  • Retrofit capability - existing completions
  • Multizone monitoring
  • Open-hole monitoring
