Intelligent Sampling

The ORIGIN sampling system allows bottom hole samplers to be triggered individually and on demand in optimum conditions.

Specifications

LOW PRESSURE ORIGIN CARRIER:

5.390/139.906

OD (MAX) (IN/MM)

2.25/57.15

ID (MIN) (IN/MM)

39.7/12.1

Length (FT/M)

HIGH PRESSURE ORIGIN CARRIER:

5.390/139.906

OD (MAX) (IN/MM)

2.25/57.15

ID (MIN) (IN/MM)

39.7/12.1

Length (FT/M)

17740

Burst (PSI)

Applications

  • To capture bottom hole samples in optimum conditions

Features

  • Multiple tools can be run at the same time, to allow samples to be taken during testing of each zone
  • Integrated with proven Metrol PARAGON Telemetry system
  • Long battery life with power save functionality, for extended well testing
  • Removes uncertainty of conventional ‘blind’ pressure activation with bi-directional real time communications

Benefits

  • Often it is not necessary to designate specific sample flow periods
  • Coded digital trigger sequence is an option for annulus pressure pulse fire.
  • PARAGON annulus pressure pulses can be optimally configured where wireline accessibility is an issue

eg:

i) Dual zone test beneath a packer and TCP guns

ii) Deviated or horizontal sections
